LENS:  White High-Impact Acrylic

MOUNTING:  Ground Mount – 4 RP-42 Black ABS Stabilizing Fins
Deck Mount – U-bracket with 4 Mounting Screws (Add -DM to part number)

FINISH:  Aluminum – Black texture polyester powder coat. Optional finishes available.
Brass – Unfinished brass. Optional finishes available.
ABS – Black or Rubbed Verde.

SINGLE TUBE COMPACT FLUORESCENT

LAMP:  5, 7, 9 or 13 watt CFL T4 single tube, 4100K, 10,000 hour (26w -2x 13w max)

BALLAST:  Internal Type 1 outdoor magnetic clamped core ballast. 120v primary amp draw of 0.165, not including lamp wattage. 5w and 7w CFL operate off same ballast and are interchangeable. 240v and 277v options available. Consult factory for details.

SOCKET:  G23 2-pin

TRIPLE TUBE COMPACT FLUORESCENT

LAMP:  26, 32 or 42 watt Triple Tube CFL, 4100K, 10,000 hour (42w max)

BALLAST:  120-277volts 50/60Hz Type 1 outdoor multi-voltage high power factor electronic program star ballast, primary draw .55A/120v thru .22A/277v

SOCKET:  GX24Q-3 4pin
